Radial 72 Frame Extractor - 12V/220V - Stainless Steel

Power supply 230V with frequent modulator with motor with reducer 0,75 kW. Constructed in 1mm acid proof stainless steel  brushed with a stainless steel valve welded to the tank. The legs and top bar are stainless steel. Please note the finish of the Stainless Steel is brushed not marble finish like on the photo.

Height 1550mm

Drum Height 800mm

Weight 95kg

Maximum frame size 270 x 450 mm

This Extractor has got 2 outlet valves: 1 of 56mm diameter which is located really close to the bottom of the drum and the second valve is 44mm diameter located higher and to the side of the main valve. With this solution you can be sure to get all the honey quick enough out of the extractor.
